Prices as of 12-10-12 prices subject to change without notice.
THE BASIC PACKAGE PRICES ARE BELOW :
FULL COMPLIANCE COST FOR A 20 FT CARAVAN IS $4500
FULL COMPLIANCE COST FOR A 22 FT CARAVAN IS $4750
FULL COMPLIANCE COST FOR A 25 FT CARAVAN IS $5000
FULL COMPLIANCE COST FOR A 30 FT + CARAVAN IS $ 5500
FULL COMPLIANCE COST FOR A 26 FT 5TH WHEEL IS $5000
FULL COMPLIANCE COST FOR A 30 FT + 5TH WHEEL IS $5500
We can supply both gas(LPG) and electrical certificates for most Australian states at $250 each .
HOWEVER YOU CAN HAVE US DO JUST ONE ITEM , 2 OR MORE OR THE LOT , ITS UP TO YOU
BASIC PACKAGE :
LEFT SIDE OR REAR DOOR
ENTRY STEP OR STEPS
ELECTRICAL :
FOR THE ELECTRICAL WE PUT AN OUTDOOR 240V INLET ON THE OUTSIDE
240 VOLT OUTSIDE 15 AMP POWER INLET
7500 WATT ISOLATED STEP DOWN TRANSFORMER FOR WHAT WILL REMAIN ON 110 V
NEW DOUBLE POLE AUSTRALIAN CIRCUIT BREAKERS AND SWITCHBOARD FOR 240V
REWIRED WITH MULTI STRAND WIRE FOR ALL 240 V CIRCUITS
DOUBLE POLE RCD'S
POWER POINTS CHANGED TO DOUBLE POLE DOUBLE THROW WITH DOUBLE SWITCHED POWER POINTS
CARAVAN WILL BE FULLY OPERATIONAL AND SAFE ON 240 VOLT ,IT WILL HAVE 2 FULLY PROTECTED CIRCUITS
PLUG INTO 240 V AND ENSURE ALL SYSTEMS ARE OPERATIONAL
GAS SYSTEM :
INSTALL NEW AND CHANGE ALL GAS PIPING TO COPPER PIPING ,
INSTALL COMPLIANT SHUTOFF VALVES IN FRONT OFF ALL GAS APPLIANCES
USE ONLY HARD SOLDER IN CONNECTIONS
CHANGE GAS BOTTLE CONNECTIONS TO STAINLESS BRAIDED AUSSIE COMPLIANT
WE CANNOT SHIP GAS / LPG BOTTLES WITH THEM
TEST
IT DOES NOT INCLUDE
NEW GAS APPLIANCES
HITCH :
CUT OFF EXISTING US FACTORY HITCH
WELD AND BOLT ON NEW AUSSIE 3500 KG HITCH WITH HAND BRAKE ATTACHMENT
CAR CONNECTION
CUT OFF US CAR CONNECTION
INSTALL AUSSIE NEW 7 PIN CAR PLUG
TAILIGHTS :
REMOVE EXISTING US TAIL LIGHTS
INSTALL NEW AUSSIE LED TAILIGHTS
AUS COMPLIANT HITCH 3500 KG RATING WITH HAND BRAKE
 |
Australian compliant hitch 3500 KG rating with hand brake
|
 |
Australian compliant hitch 3500 KG rating with hand brake
|
|
 |
Australian compliant hitch 3500 KG rating with hand brake
|
|
VARIOUS LEFT SIDE DOORS AND ENTRY STEPS INSTALLED
 |
| Left side door added to a caravan |
 |
| Left side door added to a caravan |
|
 |
| Left side door added to a caravan |
|
 |
| Left side door added to a caravan |
|
 |
| Left side door added to a caravan |
|
GAS LINES CHANGED TO COMPLIANT COPPER WITH SHUT OFF VALVES / VENTED
 |
| Interior vent |
 |
| Gas shut off valve |
 |
| Gas shut off valves |
 |
| New copper tubing installed |
 |
| New copper tubing and gas shutoff valve |
240 VOLT INSIDE DOUBLE POLE POWER POINTS
 |
| 240V Double pole, double switch power points |
 |
| 240V Double pole, double switch power points |
|
 |
| 240V Double pole, double switch power points |
|
 |
| 240V Double pole, double switch power points |
|
 |
| 240V Double pole, double switch power points |
|
 |
| 240V Double pole, double switch power points |
|
240 VOLT DOUBLE POLE CIRCUIT BREAKERS
 |
| 240V Double pole circuit breakers |
 |
| 240V Double pole circuit breakers |
|
 |
| 240V Double pole circuit breakers |
|
 |
| 240V Double pole circuit breakers |
|
MODIFICATION PLATE / COMPLIANCE PLATE :
7500W STEP DOWN ISOLATOR TRANSFORMER FOR 110 CIRCUIT
 |
| 7500w isolated step down transformer being installed |
 |
| 7500w isolated step down transformer being installed |
|
7 PIN FLAT CAR CONNECTION
 |
| 7 pin flat car connection |
 |
| 7 pin flat car connection |
|
VENTED DOOR FOR GAS
 |
| Vented door for gas compliance |
 |
| Vented door for gas compliance |
|
Prices as of 12-10-12 prices subject to change without notice.
Aussie Spec US Caravans - Australian Compliancing
158 Granite Ave
Ontario CA 91762
909 391 4800
FAX 909 391 4880
1 300 745 961
aussiespecuscaravans@gmail.com
We can convert your US specification caravan, motorhome, or 5th wheel to meet Australian compliancing standards.
